Galvanized long pipe nipple
Galvanized long pipe nipple
Ricerca nel catalogo
Search in the catalogue
Technical features and advantages
- Made from welded tube UNI EN 10255
- Galvanized
- Tapered gas thread according to UNI EN 10226 – 1:2004
- Packed in shrink film or cardboard box
GammaRange
AllegatiAttachments
GammaRange
Technical Data
| Code | D [mm] | D ["] | DN | G | B [mm] | H [mm] | b x s [mm] | Working Load (N) | Add to Wishlist |
|---|---|---|---|---|---|---|---|---|---|
| 500bz00/ | - | - | 500 | Add | |||||
| 500bz01/ | 3/8 | 50 | 6000 | 2,0 | Add | ||||
| 500bz02/ | 1/2 | 40 | 6000 | 2,3 | Add | ||||
| 500bz03/ | 3/4 | 50 | 6000 | 2,3 | Add | ||||
| 500bz04/ | 1" | 50 | 6000 | 2,9 | Add | ||||
| 500bz05/ | 1 1/4 | 60 | 6000 | 2,9 | Add | ||||
| 500bz06/ | 1 1/2 | 60 | 6000 | 2,9 | Add | ||||
| 500bz07/ | 2" | 60 | 6000 | 3,2 | Add | ||||
| 500bz08/ | 2 1/2 | 80 | 6000 | 3,2 | Add | ||||
| 500bz09/ | 3" | 100 | 6000 | 3,6 | Add | ||||
| 500bz10/ | 4" | 100 | 6000 | 4,05 | Add |
AllegatiAttachments
3 attachments:
-
Technical Data Sheet
89 KB -
Technical specifications
90 KB -
Estratto-UNI-EN-10226-Filettatura (1)
113 KB
