Two-piece pipe clamp with hole – AISI 304
Two-piece pipe clamp with hole – AISI 304
Ricerca nel catalogo
Search in the catalogue
Technical specifications and advantages
- Made of AISI 304 stainless steel
- Rounded edges, no sharp edges
- Closing screws:M6
- Pre-assembled
- With hole for bolt fixing
- On request available in AISI 316
GammaRange
AllegatiAttachments
GammaRange
Technical Data
| Code | D [mm] | D ["] | DN | G | B [mm] | H [mm] | b x s [mm] | Working Load (N) | Add to Wishlist |
|---|---|---|---|---|---|---|---|---|---|
| 6167021 | 1/2” | 2,5 | 25 | Ø 8,5 | 66,5 | Add | |||
| 6167027 | 3/4" | 2,5 | 25 | Ø 8,5 | 72 | Add | |||
| 6167034 | 1" | 2,5 | 25 | Ø 8,5 | 78,7 | Add | |||
| 6167042 | 1" 1/4 | 2,5 | 25 | Ø 8,5 | 87,5 | Add | |||
| 6167048 | 1" 1/2 | 2,5 | 25 | Ø 8,5 | 93,5 | Add | |||
| 6167060 | 2" | 2,5 | 25 | Ø 8,5 | 105,5 | Add | |||
| 6167076 | 2” 1/2 | 2,5 | 25 | Ø 8,5 | 98 | Add | |||
| 6167090 | 3" | 2,5 | 25 | Ø 8,5 | 134 | Add | |||
| 6167110 | 4" | 2,5 | 25 | Ø 8,5 | 159,5 | Add |
AllegatiAttachments
1 attachment:
-
Technical Data Sheet
145 KB
